INSIDE DIAMETER

0.656 INCHES NOMINAL

NONMETALLIC HARDNESS RATING

55.0 MINIMUM SHORE DUROMETER A AND 65.0 MAXIMUM SHORE DUROMETER A

MAJOR OUTSIDE DIAMETER

2.900 INCHES NOMINAL

SPECIAL FEATURES

ITEM MADE IN 2 MATHCED SECTIONS

HEIGHT

5.040 INCHES NOMINAL

MATERIAL

STEEL BUSHING

MATERIAL

STEEL WASHER

MATERIAL DOCUMENT AND CLASSIFICATION

ASTM A513, COMP 1+26, TYPE 5 ASSN STD SINGLE MATERIAL RESPONSE BUSHING

MATERIAL DOCUMENT AND CLASSIFICATION

ASTM A569 ASSN STD SINGLE MATERIAL RESPONSE OR ASTM A366 ASSN STD SINGLE MATERIAL RESPONSE WASHER

MAXIMUM LOAD RATING

NOT RATED

RIGID MEMBER MATERIAL AND LOCATION

STEEL,ASTM A513,CQMP 1P26, TYPE 5,BUSHING

RIGID MEMBER MATERIAL AND LOCATION

STEEL, ASTM A569 WASHER OR STEEL, ASTM A366 WASHER

SHAPE

RECTANGULAR
